Surface Mounted, Frame Contact Lift with Front and Rear 3 Stage Arms with truck adapter and (4) FJ6171-1 Extension 3-1/2″ tall and (4) FJ6171-2 Extensions 5″ tall. Servicing larger fleet vehicles is a snap with this heavy duty lift. Double-S shaped columns and single-piece construction virtually eliminate column distortion.12, 000 lbs. Capacity lift designed for a normal shop application doing truck and van work. Features a 81-1/16 inch rise. Requires a ceiling height of 13′ 8 in minimum.
Allows for 102 inches of drive through clearance. This lift available with one or two foot extended height for even more clearance. Note – Forklift is needed for unloading. Description Surface Mounted, Frame Contact Lift with Front and Rear 3 Stage Arms with truck adapter and (4) FJ6171-1 Extension 3-1/2″ tall and (4) FJ6171-2 Extensions 5″ tall. Servicing larger fleet vehicles is a snap with this heavy duty lift. Double-S shaped columns and single-piece construction virtually eliminate column distortion.12, 000 lbs. Capacity lift designed for a normal shop application doing truck and van work.
Spo12 Rotary Lift Manual
Features a 81-1/16 inch rise. Requires a ceiling height of 13′ 8 in minimum. Allows for 102 inches of drive through clearance. This lift available with one or two foot extended height for even more clearance.
Note – Forklift is needed for unloading. Additional information Features This Rotary Two-Post Symmetrical Auto Lift for cars and light trucks is rated for a 12,000 lb capacity, designed for a normal shop application, perfect for plumbing trucks, electrician vehicles, and other commercial fleet applications. Comes with 3 stage arms and (4) FJ6171-1 extensions 3 1/2' tall and (4) FJ6171-2 extension 5' tall. This surface-mounted, frame-contact lift features an 81-1/16'. This standard-height lift operates on 220V 20-amp single-phase electric and requires 13' 8' overhead clearance for installation, with a recommended bay size of 12' x 26'. This lift available with one or two foot extended height for even more clearance.
This lift is ideal for the shop doing truck and van work. Technical Specs Lift Capacity (lbs.) 12,000, Max. Rise (in.) 80, Drive-Thru Clearance (in.) 102, Overall Height (in.) 80, Overall Width (in.) 137 5/8, HP 2, Time of Full Rise (seconds) 60 Extended Information Engineered for Productivity For decades, Rotary Lifts has been the recognized leader in vehicle service lifts. This legendary reputation has set the standard for quality, durability, reliability and attention to safety throughout the automotive service market. Service and Support With Rotary lifts, you have the service and support you need. Our world-wide network of service companies are always standing. Lift Safety Standards Most of our lifts are third party tested by ETL and certified by ALI to meet or exceed strict ANSI standards such as cable cut and deformation tests.
Rotary Lift Spo12 Parts Manual
Be sure the lift you buy has the gold ALI/ETL label that assures your lift has been tested to meet these standards. Technician Productivity Features Unlike most other lifts, Rotary Lifts power units are designed and built by for Rotary lifts. We dont use 3rd party power units which are for universal applications. Adjustable height option on two-post column extensions gives you flexibility during installation to maximize the vehicles you can service with each lift.
The patented Double S (US Patent No. 5,009,287) single piece construction column design provides a channel for the bearings to travel that maximizes the strength of the column and surface contact area of the bearing. Slider block bearings of Tivarﾮ 1000 polyethylene are self-lubricating and maintenance free. Arm restraints make positioning of arms easy. They engage when the lift is raised and automatically disengage when the lift is fully lowered.
High-pressure cylinders in each column provide maximum lifting force and smooth operation. Overhead padded switch bar to prevent damaging a vehicle from being raised too high. Standard three-position flip-up adapters allow for quick and easy contact with pickup points on a variety of vehicles.
We offer the highest standard adapter reach in the industry, often avoiding the need for additional adapters. Low profile arm design on all 10,000 lbs. Capacity models (4 from floor to flip-up adapter min. Height) accommodate more vehicles. Three-Stage/Front and Two-Stage/Rear arms: The three-stage arm increases overall arm sweep and minimum arm reach to precisely lift vehicles that have: Uni-body construction Visually marked pick-up points on the vehicle Wider wheelbase and lower profile A short or long wheelbase Flat Rate Shipping 497.55.
